Setup

From Unboxing to First Share

Setting up a NAS takes an afternoon, not a weekend. The order matters more than the speed: get storage, accounts and updates right before you pour a decade of photos into it.


  1. Pick a home for the box

    A NAS wants a cool, ventilated shelf near your router, not a cupboard with no airflow. It needs a wired Ethernet connection; Wi-Fi is not an option on these devices and would be too slow anyway. If power cuts are common where you live, a small UPS (uninterruptible power supply) with a USB link lets the NAS shut down cleanly instead of losing writes mid-flight. APC and CyberPower units are widely supported by DSM and QTS.

  2. Install the drives

    Slide each drive into its tray; most trays are tool-less, with clips for 3.5-inch disks. Use NAS-rated drives such as WD Red Plus or Seagate IronWolf, ideally bought from two different shops so they come from different manufacturing batches. Note the serial numbers on paper. If a drive later fails, you'll want to know which physical bay to pull.

  3. Power on and find it

    Plug in Ethernet and power, wait for the status light, then find the box from a computer on the same network. Synology uses find.synology.com or the Synology Assistant app; QNAP uses Qfinder Pro; UGREEN and TerraMaster have their own discovery tools and mobile apps. The installer downloads the latest operating system directly, which is better than trusting whatever was on the box at the factory.

  4. Create the storage pool

    This is the one decision that is hard to undo. Choose your RAID type (two drives: RAID 1 or SHR; four drives: SHR or RAID 5, or RAID 6 / SHR-2 for extra safety) and pick Btrfs as the file system where offered, because it enables snapshots and data-integrity checks. Expect the initial build to run for hours; you can keep configuring while it works. Our RAID guide explains each choice.

  5. Lock down accounts

    Create a personal administrator account with a long passphrase, then disable the default "admin" account. Turn on two-factor authentication using an authenticator app. Make a separate standard account for each family member; nobody should browse family photos as an administrator. Enable automatic security updates, and turn on the auto-block feature that bans IP addresses after repeated failed logins.

  6. Make your first shared folder

    Create a small number of shared folders with clear purposes: Photos, Documents, Backups, Media. Enable snapshots on each with a sensible schedule — hourly for Documents, daily for Photos — and keep a few weeks of history. Grant permissions per folder: children might read Media but not Documents. Then map the share on your computer via SMB (Windows Explorer or macOS Finder's "Connect to Server").

  7. Bring the phones in

    Install the photo app on each phone — Synology Photos, QNAP QuMagie, or a container like Immich — and enable background upload. Leave it on Wi-Fi and charging overnight for the first sync; a few years of phone photos can mean tens of thousands of files. Only once everything is safely on the NAS should you consider trimming your cloud subscription.

  8. Plan remote access carefully

    Resist forwarding ports on your router. Use the vendor's relay service (QuickConnect on Synology, myQNAPcloud Link on QNAP) for casual access, or better, install Tailscale or set up a WireGuard VPN on your router so the NAS never faces the open internet. Then set up the off-site copy described in our backup plan.

After the First Week

Check the storage manager for drive health warnings, confirm snapshots are being created, and test-restore a single file from a snapshot so the process is familiar before you need it. Schedule a monthly data scrub, which reads every block and repairs silent corruption using the RAID's redundancy. Set email or push notifications so drive failures don't go unnoticed for months. A NAS that quietly reports its health is a NAS you can forget about most days, and that is exactly the goal.
